ACL HX Race Rod Bearings HX Toyota Tundra 05-14 Tacoma 05-15 FJ Cruiser 07-14 4Runner 03-17 1GR-FE

ACL Race Rod Bearings are the perfect bearing upgrade when building an engine. Whether you are building a record-breaking dyno crusher or just rebuilding your daily driver's engine, ACL Bearings are cost effective and dependable. These bearings have an HX at the end of the part number because they are .001" thinner than stock. This allows for more oil clearance which is a popular preference for engines being built for performance use. Always consult with your machine shop before buying bearings to determine which size would be optimal for your proposed use.

ACL Race Series Performance Engine Bearings


The unique combination of design, metallurgy and engineering come together to deliver what drivers expect from high performance Trimetal engine bearings. Designed to withstand higher RPM conditions


Features:

• High strength overlay plate with reduced thickness for improved fatigue properties
• Hardened steel backs on all rod bearings to improve the support of the bearing lining and assist with bearing retention in the housing.
• Increased crush for improved bearing retention
• Elimination of flash plating on the back of the bearings to improve heat transfer through the bearings and to maximize the grip between the bearings and its housing.
• Increased eccentricity to compensate for bore distortion at high rpm and to assist in the formation of hydrodynamic oil films.
• 3/4 grooved Main Bearings to optimize bearing load carrying surface area and oil flow to the conrod bearings.
• Tight consistent wall tolerances to help you maintain consistent clearances.
• Enlarged ID chamfers on bearing edges where required to accommodate large fillet radius on performance crankshafts.
